The following characteristics are applicable to all "Relax 2" strand diameters:- |
* | Minimum breaking elongation of 3.5%. |
* | Modulus of Elasticity (MOE) of 195 GPa }10 GPa based on a chord drawn on the slope between 20% and 70% of the maximum load, unless otherwise specified by the customer. |
* | Curvature (Straightness) - <=9.50mm : maximum of 35 mm; >9.50mm : maximum of 25 mm. |
* | Maximum relaxation after 1000 hours:- @ 80% of maximum breaking force.3.5%; @ 70% of maximum breaking force.2.5%. |
| Nominal type, nominal diameter and nominal tensile strength are for designation purposes only. |
| Other strand diameters and tensile grades are available on request. |
